1

X,Y,Z Working Area

1300mmx2500mmx200/300mm

2

Machine Size

2000mmx3000mmx1800mm

3

X,Y,Z Traveling Positioning Accuracy

±0.03/300mm

4

X,Y,Z Repositioning Accuracy

±0.03mm

5

Table Surface

T-slot Table(Option:Vacuum and T-slot Combined Table )

6

Frame

Welded Structure

7

X, Y Structure

Rack and Pinion Drive, Hiwin Rail Linear Bearings

8

Z Structure

Hiwin Rail Linear Bearings and Ball Screw

9

Power Consumption

≤3KW(Without Spindle)

10

Rapid Travel Rate

≤33000mm/min

11

Working Speed

≤25000mm/min

12

Spindle Power

3KW

13

Spindle Speed

0-24000RPM

14

Drive Motors

Stepper System(Servo motor as optional)

15

Working Voltage

AC380V/50/60Hz,3Phs (Option: 220V)

16

Command Language

G Code

17

Operating System

Ncstudio System(Options:DSP /Syntec Software)

18

X,Y Resolution

<0.03mm

19

Collet

ER20

20

Software Compatibility

Artcam Software, (Option:Type3 Software)

21

Running Environment Temperature

0 - 45 Centigrade

22

Relative Humidity

30% - 75%

23

Packing Size

2270mmx3100mmx2050mm

24

N.W.

1000KG

25

G.W.

1100KG

26

Optional Parts

Air Cooling Spindle

Syntec Control System

Dust Collector

Rotary System

Mist-cooling System

850W Yaskawa/750W Panasonic Servo Motors
