Laser Source Brand

Raycus/ MAX/ JPT/ IPG

Output Power(W)

20W

30W

50W

100W

Wavelength（nm）

1064nm

Output spot diameter（mm）

7±1

Beam Quality(M²)

<1.5

<1.8

Repeat Frequency(Khz)

10Khz— 200Khz

Single Pulse Energy(mJ)

0.8mJ

1mJ

Pulse width(ns)

80-100

90-120

90-130

90-130

Beam Divergence

-0.3 to +0.3mrad

Laser Class

IV

Resolution

18μ

Repeat ability

50μ

Marking Scope

110*110mm/ 150*150mm/ 200*200mm/ 300*300mm

Linear Speed

800 character/ s

Marking Linear Speed

≤18,000mm/s

Marking Depth

<1mm

Line Width

≥0.012mm

Character Size

≥0.15mm

Repeat Accuracy

±0.003mm

Cooling system

Air cooling

Power consumption(W)

120

170

240

340

Working temperature（℃）

0-40

Graphic Format Supported

bmp,jpg,gif,tga,png,tif,ai,dxf,dst,plt,etc.

Working voltage

110V/220V

Laser Module Life

>100000 hours
